SHERLO STANDALONE PANIC BUTTON ALARM SYSTEM
APPLICATIONS
- Office panic
- Shop panic
- Home panic
- Factory panic
- Guard house panic
Designed to be wired to a static hardwired panic button as well as work with Remote panic buttons. When a Panic is activated the unit will trigger the 3 Minute siren output as well as the Radio output & a Latching Strobe output. All activations can be reset via either the Remote control or the Hardwired Panic button. Our Low battery cut-out @ 10V DC will safeguard the battery from deep discharge.
FEATURES
- Microprocessor Controlled charging output.
- Low battery switch off at 10V DC.
- Buzzer tones on battery low and AC Fail.
- Resettable Fuse protection on output.
- Fuse protection on AC input.
- ABS Plastic enclosure.
SPECIFICATIONS
- Input Voltage Range: 110V ~ 230V AC 50Hz
- Output Voltage: 13V ~ 14.4V Adjustable
- Max Current output: 3.2A DC @ 14V
- Relay contact rating: 10A
- AC Fail output rating: 140mA Positive switching
- Operating temp: -3°C to 60°C
- Dimensions (lxbxh): 200 x 180 x 87mm
- Gross Weight: 0.895Kg
- Warranty: 12 Months
Whats Included :
- Fixed Panic Panel: FPP
- 1 Button Pennant Remote (sold separately)
