RUIJIE – 24 Port Gigabit PoE+ Switch

Power and performance built for professional CCTV and smart-network installations. The RUIJIE 24 Port Gigabit PoE+ Switch combines enterprise-level speed with intelligent cloud management, giving you the reliability and scalability needed for modern security and automation systems. Featuring 24 × Gigabit RJ-45 ports with PoE+ support and 4 × 10 Gb SFP+ uplinks, it’s designed to power cameras, access points, and IP devices efficiently — all managed through the Ruijie Reyee Cloud platform.

Why South African installers love it

• Full Gigabit PoE+ performance: 24 × 10/100/1000 Mbps PoE+ ports (IEEE 802.3af/at) and 4 × 10 Gb SFP+ uplinks deliver seamless data and power for high-demand CCTV systems.
• Cloud-managed simplicity: Configure, monitor, and manage remotely via the Reyee Cloud App or Web Portal — ideal for multi-site or off-grid setups.
• Optimised for CCTV networks: IP-camera recognition, port isolation, broadcast storm control and auto-recovery keep your footage flowing and your network stable.
• Enterprise-grade speed: Switching capacity up to 128 Gbps and forwarding rate around 95 Mpps ensure no bottlenecks during high traffic loads.
• Reliable for local conditions: Surge protection up to 6 kV, operating range 0 °C to 50 °C, and 5-year warranty for peace of mind in South African climates.

Specifications & features

Model	RUIJIE 24 Port Gigabit PoE+ Switch (RG-NBS3200-24GT4XS-P)
Ports	24 × 10/100/1000 Base-T PoE+ (RJ-45) + 4 × 10 Gb SFP+ uplinks
Switching capacity	128 Gbps
Forwarding rate	≈ 95 Mpps
PoE budget	370 W total (IEEE 802.3af/at compliant)
MAC address table	16,000 entries
VLANs supported	Up to 4094
Surge protection	±6 kV (common & differential mode)
Operating temperature	0 °C – 50 °C
Management	Cloud-enabled via Reyee Cloud Platform and mobile app
Warranty	5 Years

Where it’s perfect

• CCTV systems: Powers and connects up to 24 IP cameras for offices, homes or business parks with zero lag and high stability.
• Smart buildings & automation: Ideal for networking access control systems, intercoms, and Wi-Fi access points with clean PoE+ distribution.
• Commercial and industrial networks: Robust enough for data centres and enterprise applications needing fast uplinks and secure traffic segmentation.

Installation tips

• Install in a well-ventilated cabinet or rack with sufficient airflow and dust protection.
• Label each port clearly for zone tracking (“Front Cameras”, “Gate Access”, “Uplink”).
• Use surge protectors and a UPS to guard against power spikes or load-shedding interruptions.
• Update firmware via the Reyee Cloud App to access new features and enhanced security patches.

Frequently Asked Questions

Boost your network’s power and reliability today. Add the RUIJIE 24 Port Gigabit PoE+ Switch to your setup and experience true enterprise-grade performance for CCTV, automation and smart connectivity in South Africa.
