Compression and Recording

---

• H.265 Pro+ can be enabled to improve encoding efficiency and reduce data storage costs
• Full channel recording at up to 4 MP lite resolution

Storage and Playback

---

• Two SATA interfaces
• Smart search for efficient playback�

Smart Function

---

• Support multiple VCA (Video Content Analytics) events for both analog and smart IP cameras
• Support 4-ch line crossing detection and intrusion detection; DS-7216HQHI-K2 supports 1-ch sudden scene change detection

Network & Ethernet Access

---

• Hik-Connect & DDNS (Dynamic Domain Name System) for easy network management
• Max. 48/96 Mbps incoming bandwidth and output bandwidth limit configurable

�

RECORDING

---

• Video compression: H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
• Encoding resolution: When 1080p lite mode is not enabled: 4 MP lite/3 MP/1080p/720p/VGA/WD1/4CIF/CIF When 1080p Lite mode is enabled: 4 MP lite/3 MP/1080p lite/720p lite/VGA/WD1/4CIF/CIF
• Video bit rate: 32 Kbps to 6 Mbps
• Dual stream Support
• Stream type: Video, Video & Audio
• Audio compression: G.711u
• Audio bit rate: 64 Kbps

�

VIDEO AND AUDIO

---

• IP video input:�Up to 6 MP resolution

• Analog video input: 8ch to 16ch
• HDTVI input:4 MP, 3 MP, 1080p30, 1080p25, 720p60, 720p50, 720p30, 720p25 *: The 3 MP signal input is only available for channel 1/2 of DS-7208HQHI-K2, and for channel 1/2/3/4 of DS-7216HQHI-K2
• AHD input: 4 MP, 1080p25, 1080p30, 720p25, 720p30
• HDCVI input: 1080p25, 1080p30, 720p25, 720p30
• CVBS input:�PAL/NTSC
• CVBS output: 1-ch, BNC (1.0 Vp-p, 75 ?), resolution: PAL: 704 � 576, NTSC: 704 � 480

FOR MORE INFO CHECK OUT THE�DATA SHEET
