Specialist scopes designed by air-gunners for air-gunners!

Air-max scopes feature our H2 optics in a variety of configurations designed to suit air-gun characteristics.

• Capped Target Turrets
• 30mm Mono-Tube Chassis
• Wide Angle
• Side Focus
• Illumination
• 16 Layer Fully Multi-Coated Lenses
• High Torque Zoom Ring
• Fast Focus Eye bell
• AMX Reticle Designed For Air-guns

Nitrogen purged. Shockproof. Waterproof. Fog proof.

All caliber rated.

Hawke Warranty.

AMX Reticle

Both the AMX and AMX IR glass etched reticles are based on the spacing of a 10x Mil Dot. The AMX offers multiple aim points, useful when shooting air guns with loopy trajectories.

Half Mil Dot spacing on the lower post provides increased aim points for long shots.

The horizontal bars are calculated at 0.5, 1.5, 2.5, 3.5 and 4.5 mil spacing. Hollow posts are segmented into mil spacing and can be used for bracketing.



Technical Specifications;

Length:	277mm 10.9"
Weight:	589g 20.8oz
Eye relief:	76mm 3"
Focus/Parallax - Side Focus	9m - ∞ 10yds - ∞
Field of View:	14.6 - 3.6m @100m 43.7 - 10.9ft @100yds
Exit Pupil:	13.3-3.3mm 0.52-0.13"
Chassis:	30mm Mono-tube
Optical System:	3-12x
Objective:	40mm
Illumination:	Red
Reticle:	AMX IR
Elevation Increment:	1⁄10 MRAD
Elevation Adjustment Range:	30 MRAD
Windage Increment:	1⁄10 MRAD
Windage Adjustment Range:	30 MRAD
Material:	Aluminium
Ocular Type:	Fast Focus
Lens Coating:	Fully Multi-Coated - 16 Layers
Power Selector Style:	Knurled Posi-Grip
Focal Plane:	Second Focal Plane (SFP)
Turret Caps:	Yes
Turret Type:	Capped Target Turrets
