An extensive range of scopes to suit all calibres and disciplines.

IR models feature precision glass etched reticles with multi-stage illumination in both red and green.

• Capped Low-Profile Turrets
• 1 Inch Two piece Tube Chassis
• Adjustable Objective For Parallax Correction
• Illumination
• 11 Layer Fully Multi-Coated Lenses
• High Torque Zoom Ring
• Fast Focus Eyebell

Nitrogen purged. Shockproof. Waterproof. Fog proof.

All calibre rated.

Hawke Warranty.

Mil Dot Illuminated Reticle

The classic Mil Dot features multiple aim points for hold-over and hold-under. Accurate mil spacing on 10x, featuring 4 Mil Dots in each direction. Glass etched reticle that has 5 brightness levels of illumination in both red and green, or can be turned off for a solid black reticle.





Technical Specifications;

Length:	388mm 15.3"
Weight:	620g 21.9oz
Eye relief:	89mm 3.5"
Focus/Parallax – AO	14m - ∞ 15yds - ∞
Field of View:	7.8-2.1m @100m 23.6-6.2ft @100yds
Exit Pupil:	13-3mm 0.5-0.1"
Chassis	1" Two-piece assembly
Optical System	4-16x
Objective	50mm
Illumination	Red / Green
Reticle	Mil Dot
Elevation Increment	1⁄4 MOA
Elevation Adjustment Range:	65 MOA
Windage Increment	1⁄4 MOA
Windage Adjustment Range	65 MOA
Material	Aluminium
Ocular Type	Fast Focus
Lens Coating	Fully Multi-Coated - 11 Layers
Power Selector Style	Knurled Posi-Grip
Focal Plane	Second Focal Plane (SFP)
Turret Caps	Yes
Turret Type	Low Profile



Downloads;

• Product instructional manual can be downloaded here


External Media;
(Product video walk-around and showcase)
